BENTSAI BT-HH6205B Portable Handheld Inkjet Printer

BENTSAI BT-HH6205B – Portable Handheld Thermal Inkjet Printer

Product Overview

The BENTSAI BT-HH6205B is a handheld coding printer based on Thermal Inkjet (TIJ) technology. It supports text, numbers, dates, batch codes, counters, logos, images, barcodes, QR codes, and Data Matrix codes, with a maximum print height of 12.7 mm and a maximum print speed of 30 m/min.

It features a 4.3-inch HD touchscreen, FreeRTOS, 128M embedded memory, and two 2600mAh 18650 lithium-ion batteries with operating time of up to 16 hours according to the manufacturer.

Key Features

• Thermal Inkjet technology for handheld coding and marking.
• 2.5–12.7 mm print height with 1–5 lines.
• 600 / 300 dpi print resolution.
• Maximum print size: 12.7 × 406 mm.
• Maximum print speed: 30 m/min.
• 4.3-inch HD touchscreen.
• 2 × 2600mAh 18650 batteries, up to 16 hours operating time.
• Arabic is listed among available system languages, subject to regional language configuration.
• Supports QR Code, Data Matrix, GS1 Data Matrix, and multiple 1D barcode formats.

Technical Specifications

• Model: BT-HH6205B / HH6205B.
• Operating Mode: Handheld only.
• Printhead: 12.7 mm / 0.5 inch.
• Printing Technology: Thermal Inkjet.
• Print Height: 2.5–12.7 mm.
• Print Lines: 1–5.
• Resolution: 600 / 300 dpi.
• Maximum Print Size: 12.7 × 406 mm.
• Maximum Print Speed: 30 m/min.
• Display: 4.3-inch HD Touch Screen.
• Operating System: FreeRTOS.
• Embedded Memory: 128M.
• Battery: 2 × 2600mAh 18650 Li-ion.
• Operating Time: Up to 16 hours.
• Charging: USB-C 5V/2A.
• I/O Interface: USB-A.
• Dimensions: 126 × 43 × 206 mm.
• Weight: 420 g.
• Working Temperature: 5°C to 35°C.
• Storage Temperature: -20°C to 55°C.
• Humidity: 10% to 80%.
• Ink Throw Distance: 2–5 mm.

Supported Content

Supports text, numbers, images, logos, dates, counters, databases, barcodes, and 2D codes. Supported image formats include JPG, JPEG, PNG, and BMP. 1D barcode formats include Code 128, Code 39, EAN-8, EAN-13, UPC-A, UPC-E, ITF 2 of 5, and ITF-14. 2D formats include QR Code, Data Matrix, and GS1 Data Matrix.

Inks and Printable Materials

Water-based inks are intended for porous and semi-porous materials such as paper, corrugated boxes, wood, fiberboard, and textiles. Solvent quick-drying inks are intended for semi-porous and non-porous materials such as plastic, glass, metal plates, aluminium foil, and cables. Cartridge selection should match the target surface.

Listed Accessories

1 ink cartridge, 1 USB flash drive, 1 detachable auxiliary roller, 1 positioning plate, and 1 USB charging cable.

Who Is It Suitable For?

Suitable for warehouses, factories, retail operations, and packaging workflows that need portable printing of dates, batch codes, barcodes, QR codes, and logos directly on different materials without permanently mounting the printer to a production line.

Before You Buy

• HH6205B is handheld-only. Sensor-port and inline automatic operation belong to the HH6205BL variant, not this model.
• Maximum print height on this model is 12.7 mm; 25.4 mm belongs to the HH6210 series.
• Select water-based or solvent quick-dry ink according to the material being printed.
• For proper printing, the manufacturer specifies a 2–5 mm ink throw distance between the nozzle plate and the print surface.
